Alienware m16 R1 Setup And Specifications

Battery
The following table lists the battery specifications of your Alienware m16 R1.
Table 16. Battery specifications
Description Values
Battery type
6-cell lithium-ion (86 Wh)
Battery voltage
11.40 VDC
Battery weight (maximum)
0.34 kg (0.75 lb)
Battery dimensions:
Height
7.56 mm (0.30 in.)
Width
295.20 mm (11.62 in)
Depth
77.70 mm (3.06 in.)
Temperature range:
Operating
● Charging: 0°C to 50°C (32°F to 122°F)
● Discharging: 0°C to 60°C (32°F to 140°F)
Storage
-20°C to 65°C (-4°F to 149°F)
Battery operating time Varies depending on operating conditions and can significantly
reduce under certain power-intensive conditions.
Battery charging time (approximate)
NOTE: Control the charging time, duration, start and
end time, and so on using the Dell Power Manager
application. For more information about Dell Power
Manager, search in the Knowledge Base Resource at
www.dell.com/support.
● Standard charging: 3 hours, when computer is turned off
● ExpressCharge: 2 hours, when computer is turned off
● ExpressChargeBoost: 20 minutes, from 0% up to 35% when
computer is turned off
Coin-cell battery
None
CAUTION: Operating and storage temperature ranges may differ among components, so operating or storing the device
outside these ranges may impact the performance of specific components.
CAUTION: Dell recommends that you charge the battery regularly for optimal power consumption. If your battery charge
is completely depleted, connect the power adapter, turn on your computer, and then restart your computer to reduce the
power consumption.
Display
The following table lists the display specifications of your Alienware m16 R1.
Table 17. Display specifications
Description Option one Option two Option three
Display type
16-inch, Quad High Definition
plus (QHD+)
16-inch, Quad High Definition
plus (QHD+)
16-inch, Full High Definition
plus (FHD+)
Display-panel technology
Wide Viewing Angle (WVA) Wide Viewing Angle (WVA) Wide Viewing Angle (WVA)
17

Alienware m16 R1 Specifications

General

Color name	Dark Metallic Moon
Form factor	Clamshell
Product type	Laptop
Product color	Black
Market positioning	Gaming
Panel type	WVA
Color gamut	100 %
Pixel pitch	0.13 x 0.13 mm
LED backlight	Yes
Pixel density	188.7 ppi
RGB color space	DCI-P3
Display diagonal	16 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	300 cd/m²
Display resolution	2560 x 1600 pixels
Native aspect ratio	16:10
Maximum refresh rate	240 Hz
Contrast ratio (typical)	1000:1
Discrete GPU manufacturer	NVIDIA
Discrete graphics card model	NVIDIA GeForce RTX 4080
On-board graphics card model	Intel® UHD Graphics
Discrete graphics card memory	12 GB
Discrete graphics memory type	GDDR6
Pointing device	Touchpad
Motherboard chipset	Intel HM770
Memory slots	2x SO-DIMM
Internal memory	16 GB
Memory clock speed	4800 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR5-SDRAM
Maximum internal memory	64 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
SSD form factor	M.2
Total storage capacity	1000 GB
Compatible memory cards	SD
Number of SSDs installed	1
Battery weight	340 g
Battery voltage	11.4 V
Battery capacity	86 Wh
Battery recharge time	3 h
Number of battery cells	6
AC adapter power	330 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	16.92 A
AC adapter output voltage	19.5 V
Audio chip	Realtek ALC3254
Speaker power	2 W
Number of built-in speakers	2
Operating shock	140 G
Operating altitude	-15.2 - 3048 m
Operating vibration	0.66 G
Non-operating altitude	-15.2 - 10668 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Front camera HD type	Full HD
Video capturing speed	30 fps
Front camera resolution	1920 x 1080 pixels
Front camera resolution (numeric)	2.07 MP
Antenna type	2x2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Bluetooth version	5.3
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN controller model	Killer Wi-Fi 6E 1675i
Wi-Fi data rate (max)	2400 Mbit/s
Ethernet LAN data rates	2500 Mbit/s
WLAN controller manufacturer	Killer
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Bus type	DMI4
Processor cache	36 MB
Processor cores	24
Processor model	i9-13900HX
Processor family	Intel® Core™ i9
Processor cache type	Smart Cache
Configurable TDP-down	45 W
Processor manufacturer	Intel
Processor boost frequency	5.4 GHz
Operating system installed	Windows 11 Home
Operating system architecture	64-bit

Weight and Dimensions

Depth	289.9 mm
Width	368.9 mm
Weight	3300 g
Height (rear)	23 mm
Height (front)	23.1 mm
