ALLEN & HEATH ME U User Manual

User Guide – AP9209_1 18 ALLEN&HEATH
9. ME-U Specification
9.1 Dimensions
9.2 Specification
Input – Card option slot – 40 channels
48kHz digital audio
ME-D (dSNAKE, ACE, Aviom
®
) card provided
Aviom
®
A-Net16 compatible -16 channels
M-Dante network card option available
M-MADI card option available
M-ES EtherSound card option available
Outputs – 10 ports
Compatible with ME mixers
Locking EtherCon connectors
PoE available on all output ports
Network Port – Ethernet TCP/IP
System setup + receiving iLive channel data
Setup – Uses PC or Mac web browser
Received or manual channel names
Received or manual odd/even stereo links
iLive mode for receiving iLive names/links
Change TCP/IP address
Default IP address = 192.168.1.40
Subnet Mask = 255.255.255.0
Default Gateway = 192.168.1.254
Mains Input – 100-240V AC 47-63Hz 250W
PoE capability – 15W at each ME-U output
Dimensions – Width x Depth x Height
2U rack - 483 x 253 x 92mm (19”x10”x3.6”)
Weight – 4.6kg (10.1lbs) unpacked
9.3 Further information
Visit the Allen & Heath web site to find out
more about the ME Personal Mixer System.
www.allen-heath.com
 ME-U application examples
 The ME System knowledgebase
 The latest ME-U operating firmware
 The latest ME-1 mixer firmware
 Allen & Heath contact for your territory
88.00
253.00
40.00173.00
482.60
92.20
353.00
76.20
