ALLEN & HEATH XB-14 MK2 User Manual

Allen & Heath 35 XB-14 MK2 User Guide
WIRING NOTES
GROUND
RETURN
SEND
RETURN
OUT
IN
SEND
INSERT
PROCESSOR
LINK RING TO SLEEVE TO UNBALANCE
T
R
S
T
R
S
T
R
S
Insert cable wiring
1= ground
2= hot (+ )
3= cold (-)
BALANCED
XLR FEMALE
RCA phono jacks
XLR MALE
2= hot (+ )
1= ground
3= cold (-)
RCA PHONO CABLE
Sleeve= ground
Ring= cold (-)
Tip= hot (+ )
BALANCED
1= ground
2= hot (+ )
3= cold (-)
2= hot (+ )
1= ground
3= cold (-)
Sleeve= ground
Ring= cold (-)
Tip= hot (+ )
BALANCED
BALANCED
BALANCED
XLR FEMALE
XLR MALE
BALANCED
UNBALANCED
Sleeve= ground
Ring= cold (-)
Tip= hot (+ )
BALANCED
Sleeve= ground
Ring= cold (-)
Tip= hot (+ )
BALANCED
UNBALANCED
adapter
UNBALANCED
INSTRUMENT CABLE
TRS JACK CABLE
MIC CABLE
TRS to XLR-F CABLE
TRS to XLR-M CABLE
TO
FROM
INPUT
OUTPUT
2 Outputs to 1 Input
Y-Adapter
No !
1 Output to 2 Inputs
Y-Adapter
Yes
General Wiring Information
