ALLEN&HEATH XB-14 service manual AP7566 Page - 2 - of 13
Release notes for this issue
Limited One Year Warranty
This product is warranted to be free from defects in materials or workmanship for period of
one year from the date of purchase by the original owner. To ensure a high level of
performance and reliability for which this equipment has been designed and manufactured,
read this User Guide before operating. In the event of a failure, notify and return the
defective unit to ALLEN & HEATH Limited or its authorised agent as soon as possible for
repair under warranty subject to the following conditions
Conditions of Warranty
The equipment has been installed and operated in accordance with the instructions in this
User Guide. The equipment has not been subject to misuse either intended or accidental,
neglect, or alteration other than as described in the User Guide or Service Manual, or
approved by ALLEN & HEATH. Any necessary adjustment, alteration or repair has been
carried out by ALLEN & HEATH or its authorised agent. This warranty does not cover fader
wear and tear. The defective unit is to be returned carriage prepaid to ALLEN & HEATH or its
authorised agent with proof of purchase. Units returned should be packed to avoid transit
damage. In certain territories the terms may vary. Check with your ALLEN & HEATH agent
for any additional warranty which may apply.
For further assistance please contact our distributor or your territory.
http://www.allen-heath.com/UK/distributors.asp

Other manuals for ALLEN & HEATH XB-14

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ALLEN & HEATH XB-14 and is the answer not in the manual?

ALLEN & HEATH XB-14 Specifications

Operating Levels IconOperating Levels
Mono channel Mic input range+6 to –63dBu
Mono channel Line input range+10 to –26dBu
Insert point nominal level0dBu
Stereo input nominal level0dBu
Telco channel input range+10 to –26dBu
External monitor inputs nominal level0dBu
Output Levels IconOutput Levels
PGM L & R outputs nominal level+4dBu
PGM Mono output nominal level0dBu
PGM L & R inserts nominal level-2dBu
Aux output nominal level0dBu
Mix B outputs nominal level0dBu
Rec outputs nominal level0dBu
Audio Performance IconAudio Performance
THD+n Mic in to PGM L/R Out0.003%
THD+n Mic in to PGM Out0.007%
THD+n Line in to PGM L/R out0.004%
THD+n Stereo in to PGM out0.003%
Noise Mic Pre EIN-127dBu
Noise PGM out-92dBu
Frequency Response IconFrequency Response
Mic in to PGM L/R Out20Hz to 20kHz
Line in to PGM L/R out10Hz to 30kHz
Stereo in to PGM L/R out10Hz to 30kHz
Headroom IconHeadroom
Analogue Headroom Outputs21dB
USB in & out headroom14dB
Analogue Headroom Mix point24dB
Crosstalk & Attenuation IconCrosstalk & Attenuation
Mono fader attenuation 1kHz/10kHz-99/-90
Mono ON switch attenuation 1kHz/10kHz-96/-80
TELCO fader attenuation 1kHz/10kHz-99/-92
TELCO ON switch attenuation 1kHz/10kHz-102/-100
Stereo fader attenuation 1kHz/10kHz-100/-91
Stereo ON switch attenuation 1kHz/10kHz-102/-102
