4 XONE:32 User Guide
Contents
Important Safety Instructions.................3
Introduction............................................4
Quick Start.............................................5
Connectors and Panel Controls ............6
Installation ...........................................10
Cable diagrams ...................................11
Operating Instructions .........................12
Replacing the Crossfader....................14
Specification ........................................18
Glossary ..............................................20
Order Codes........................................22
Tips and Troubleshooting....................23
Introduction
Welcome to the XONE:32 professional DJ mixer. This stylish and solidly built 3 channel club format console
presents a unique combination of performance tools for the professional DJ. Above all, it features a sound
quality second to none. XONE:32 has been designed and constructed using the same rigorous standards we
apply to our large format professional consoles used and respected by top engineers and performers throughout
the world. We have had great fun designing this new range. We are sure you will get even more enjoyment
using it.
We know you want to get started right away. For this reason we have kept this user guide concise and to the
point. We recommend you read it through first. However, if even that is too much then at least read the QUICK
START page before you plug up and go.
This user guide refers to the XONE:32. For further information on the basic principles of audio system
engineering and mixing technique please refer to one of the specialist publications available from bookshops
and audio equipment dealers. Whilst we believe the information in this guide to be reliable we do not assume
responsibility for inaccuracies. We also reserve the right to make changes in the interest of further product
development.
We are able to offer further product support through our world-wide network of approved dealers and service
agents. You can also access our Web site on the Internet for information on our product range, assistance with
your technical queries or simply to chat about matters audio. To help us provide the most efficient service
please keep a record of your console serial number, and date and place of purchase to be quoted in any
communication regarding this product.
Check out our home site
www.allen-heath.com for information on the company and its pedigree, our
full product range and our design philosophy. We also have a site dedicated to the exciting XONE console
range
www.xone.co.uk.
Key Features
• 3 Stereo channels with switchable line and RIAA phono inputs
• DJ microphone input
• Separate main mix, record, booth and headphones monitor outputs
• Stereo Aux output for effects
• 3 Band +6/-26 asymmetric EQ with extended cut
• Removable VCA CROSSFADER with reverse and variable contour
• Crossfade position dependent TRANSMUTE buttons for transform and punch effects
• Analogue state variable VCF filter effects with filter type, frequency and resonance controls
• LFO filter frequency control with finger tap tempo select
• DRS™ Digital Recall System with 4 user programmable presets for filter effects
• Advanced cue system with interlock and cue/mix fader for performance preview
• Extensive channel and output metering
• Sensible layout of setup and performance controls across three surfaces
• High grade dual rail gold contact crossfader
• Universal internal power supply for any worldwide mains voltage
