ALLEN & HEATH Xone 4D Service Manual

ALLEN&HEATH Xone:4D service manual AP7337_2 Page - 11 - of 14
INTERIOR PARTS
MIDI Slave
003-523
Filter
003-525
MIDI fader
003-532
Jog wheel
assembly
003-533
Xfader
003-579
MIDI i/p pitch
003-635
MIDI i/p
control
003-636
MIDI i/p pitch
003-635
MIDI i/p
control
003-636
BPM display
7 seg LED
003-695
Analog
slaveSlave
003-854
Master
003-855
Linear fader
003-860
Stereo i/p
003-859
Note: When fitting replacement PCB check phono/line jumper positions.

ALLEN & HEATH Xone 4D Specifications

General

Sample rate	96 kHz
Frequency range	22 - 22000 Hz
Channels quantity	20 channels
Digital sound processing	24 bit
Microphone in	Yes
Product color	Black
Video capability	No
Equalizer bands quantity	3

Weight and Dimensions

Depth	358 mm
Width	432 mm
Height	88 mm
Weight	5000 g
Package depth	490 mm
Package width	575 mm
Package height	195 mm
Package weight	6000 g
