ALLEN&HEATH Xone:4D service manual AP7337_2 Page - 7 - of 14
How to order parts
Parts must be ordered from our distributor in your territory. A list of international distributors can be viewed
at http://www.allen-heath.com/UK/distributors.asp
UK parts must be ordered through an appointed A&H dealer or service centre. A list of UK service centres
can be viewed at http://www.allen-heath.com/UK/service_centres.asp
PARTS IDENTIFICATION
EXTERIOR PART
Black pot nut
AB8172
MIDI
Round black
button
AJ4251
Fader AI4999
Knob AJ4310
Light ring
AJ5324
Black button
AJ5325
Encoder AL6338
Knob AJ6379
AI8004
Knob AJ7304
Encoder AL6338
Knob AJ6379
Jog wheel deck
AJ6342
