Allen & Heath 33 ZED POWER 1000
CONNECTION DRAWING - LIVE MIXING 3
Amplifier outputs fed from Mono LR Mix and
Sub Out, connected to Mono PA system and
subwoofer

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ALLEN & HEATH Zed Power 1000 and is the answer not in the manual?

ALLEN & HEATH Zed Power 1000 Specifications

General IconGeneral
TypePowered Mixer
Channels10
Mic Inputs4
Line Inputs6
Inputs10
Power1000W
Aux Sends2
Phantom PowerYes
USBNo
EQ3-band
Weight10.5 kg
