ALLEN&HEATH ZED R-16 service manual AP7339 Page - 23 - of 24
SPECIFICATION:
Operating Levels
Inputs
Mono channel (XLR) Input -6 to –60dBu for nominal (+nndBu in max)
Mono channel Line Input (Jack socket) +10 to –26dBu (+30dBu maximum)
Insert point (TRS Jack socket) 0dBu nominal +21dBu maximum
Stereo Input (Jack sockets) 0dBu nominal (control = Off to +10dB)
Stereo input (phono sockets) 0dBu nominal (control = Off to +10dB)
2 Track Input (phono sockets) 0dBu nominal +21dBu maximum
Outputs
L, R & Mono Outputs (XLR) +4dBu nominal. +27dBu maximum.
L, R & M Insert (TRS Jack socket) -2dBu nominal +21dBu maximum
Group Outputs (Jack sockets) +4dBu nominal. +27dBu maximum.
Group Insert (TRS Jack socket) -2dBu nominal +21dBu maximum
Aux Outputs (Jack sockets) -2dBu nominal +21dBu maximum (Bal Option +4)
Matrix Outputs (TRS Jack socket) -2dBu nominal. +21dBu maximum. (Bal Option +4)
2 Track Output (phono sockets) 0dBu nominal. +21dBu maximum.
Direct Out (TRS Jack socket) 0dBu nominal. +21dBu maximum.
Headroom
Analogue Headroom from nominal (0Vu) 21dB
USB in & out headroom from nominal (0Vu) 14dB
Frequency Response
Mic in to Mix L/R Out, 30dB gain +0.5/-1dB 20Hz to 20kHz.
Line in to Mix L/R out 0dB gain +0.5/-1dB 10Hz to 30kHz
Stereo in to Mix L/R out +0.5/-1dB 10Hz to 30kHz

ALLEN & HEATH ZED R-16 FIREWIRE Specifications

General

Brand	ALLEN & HEATH
Model	ZED R-16 FIREWIRE
Category	Music Mixer
Language	English
