Appendix
A
Specifications
Appendix Objectives
Appendix A provides the specifications for the 1203-GD1 module,
1203-GK1 module, and the 1336-GM1 board.
Important:
Remote I/O communications modules are non-repairable
units.
1336-GM1 Board Specifications
The following table gives the specifications for the 1336-GM1 board.
Category Specifications
Electrical Input Voltage
Input Current
Input Frequency
SCANport Load
Supplied by the drive
Not Applicable
Not Applicable
60mA DC
Environmental Operating Temperature
Storage Temperature
Relative Humidity
0 to +50
°
C (32 to 122
°
F)
–40 to +85
°
C (–40 to 185
°
F)
0 – 95%, non-condensing
Communications Product
Controller
Baud Rates
Rack Sizes
SCANport
Allen-Bradley Remote I/O
57.6K, 115.2K, 230.4K
1/4, 1/2, 3/4, full
Mechanical Height
Width
Depth
Enclosure
71 mm (2.8")
114 mm (4.5")
127 mm (0.5")
Open (IP00)
Regulatory
Agencies
UL
CSA
CE
!
ATTENTION: The 1336-GM1 communications board
contains ESD (Electrostatic Discharge) sensitive parts.
Static control precautions are required when installing
and removing this assembly. Device malfunction may
occur if you do not follow ESD control procedures. If
you are not familiar with static control procedures, refer
to Rockwell Automation Publication 8000-4.5.2,
Guarding Against Electrostatic Damage, or other appli-
cable ESD protection handbook.
