Removable Terminal Blocks
Colored terminal blocks are removable by loosening the upper and lower
retaining screws. Black terminal blocks are not removable.
Figure 1:Installing Octal Labels
Beveled Edge
Removable
Terminal
Block
Terminal Wiring
max. #14 AWG (2mm
2
)
max. 2 wires per terminal
max. torque: 0.9Nm (8 in-lbs)
Upper Retaining Screw Maximum
Torque = 0.6 Nm (5.3 in-lbs)
Module Color Bar
Lower Retaining Screw Maximum
Torque = 0.6 Nm (5.3 in-lbs)
Octal Door Label
1746-XXXX 1746-XXXX(OCTAL)
Octal Filter Label
OCTAL
