34 Rockwell Automation Publication 1769-IN028C-EN-P - August 2016
Compact I/O Expansion Power Supplies
Certifications Compability with MicroLogix 1500
To use the 1769 expansion I/O power supply with the MicroLogix 1500 processor, the processor
(catalog number 1764-LSP or 1764-LRP) must be series A, revision C, Firmware Revision
Number (FRN) 3 or later. Look at the processor nameplate to check the firmware revision.
Status file bit S:59 (Operating System Firmware Revision Number)
If your processor is at an older revision, you must upgrade the operating system. Go to
http://compatibility.rockwellautomation.com/Pages/home.aspx
to download the firmware
update.
Additional Resources
Resource Description
CompactLogix Power Supplies Specifications Technical Data,
publication 1769-TD008
Provides a detailed description of the 1769 CompactLogix power
supplies.
Compact I/O 1769-ADN DeviceNet Adapter User Manual,
publication 1769-UM001
Provides information on how to install and use a 1769-ADN
DeviceNet adapter.
Compact I/O Analog Modules User Manual,
publication 1769-UM002
Provides information on how to install and use Compact Analog I/O
modules.
CompactLogix System User Manual, publication 1769-UM007
Provides information on how to install and use your CompactLogix
controller.
MicroLogix 1500 Programmable Controllers User Manual,
publication 1764-UM001
Provides information on how to install and use your Compact I/O
with the MicroLogix 1500 programmable controller.
CompactLogix System Selection Guide,
publication 1769-SG001
Provides more information about the 1769 CompactLogix
controllers.
1769 Compact I/O Communication Bus Expansion Cables
Installation Instructions, publication 1769-IN014
Provides information install and use Compact I/O Communication
Bus Expansion Cables.
Compact I/O End Caps/Terminators Installation Instructions,
publication 1769-IN015
Provides information to install and use Compact 1769-ECL,
1769-ECR End Cap/Terminators.
Industrial Automation Wiring and Grounding Guidelines,
publication 1770-4.1
Provides general guidelines for installing a Rockwell Automation
industrial system.
Product Certifications website,
http://www.rockwellautomation.com/global/certification/
overview.page
Provides declarations of conformity, certificates, and other
certification details.
