Allen-Bradley 20A User Manual

26 Rockwell Automation Publication PFLEX-AT001L-EN-P - September 2017
Chapter 3 Evaluating the PowerFlex 7-Class Internal Resistor
PowerFlex 70 Power Curves
Figure 4 - PowerFlex 70 – 240 Volt, Frames A and B
Figure 5 - PowerFlex 70 – 240 Volt, Frame C
0 1 2 3 4 5 6 7 8 9 101112131415161718192021222324252627282930
Decel Time (Seconds)
% Peak Power
0
200
400
600
800
1000
1200
1400
1600
1800
2000
2200
2400
2600
2800
3000
240V Frames A & B
% Peak Power
0
200
400
600
800
1000
1200
1400
1600
1800
2000
2200
2400
2600
2800
3000
0 1 2 3 4 5 6 7 8 9 101112131415161718192021222324252627282930
Decel Time (Seconds)
240V Frame C
