30 Rockwell Automation Publication PFLEX-AT001L-EN-P - September 2017
Chapter 3 Evaluating the PowerFlex 7-Class Internal Resistor
PowerFlex 700 Power Curves
Figure 12 - PowerFlex 700 – 240 Volt, Frame 1, 2…5 Hp
Figure 13 - PowerFlex 700 – 240 Volt, Frame 1, 7.5 Hp
0
200
400
600
800
1000
1200
1400
1600
1800
2000
2200
2400
2600
2800
3000
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
240V Frame 1, 2…5 HP
Decel Time (Seconds)
% Peak Power
0
200
400
600
800
1000
1200
1400
1600
1800
2000
2200
2400
2600
2800
3000
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
Decel Time (Seconds)
% Peak Power
240V Frame 1, 7.5 HP
