PanelView 800 HMI Terminals 23
Publication 2711R-IN001A-EN-P - January 2015
Specifications
PanelView 800 - 2711R-T4T, 2711R-T7T, 2711R-T10T
Attribute Value
2711R-T4T 2711R-T7T 2711R-T10T
Display type Color transmissive TFT active matrix LCD, widescreen format
Display size 4 in. 7 in. 10 in.
Display area 95 x 53.9 mm
(3.74 X 2.12 in.)
153.6 x 86.6 mm
(6.05 x 3.41 in.)
211.2 x 158.4 mm
(8.31 x 6.24 in.)
Resolution (pixels) 480 x 272 800 x 480 800 x 600
Backlight lifespan, min. 40,000 hours
Operator input Analog touch and
function keys
Analog touch
External memory storage USB port and
micro-SD (Secure Digital) card – Industrial grade micro-SD cards recommended. Supports
SDSC and Class 6 & Class 10 SDHC micro-SD cards, FAT32/16 formats, up to 32 GB
maximum size.
Programming port Ethernet port
Battery lifespan, min. 5 years at 25 °C (77 °F)
Real-time clock Yes
Input voltage range 18…32V DC (24V DC nom)
Power consumption, max 9 W (0.39 A @ 24V DC) 11 W (0.40 A @ 24V DC) 14 W (0.48 A @ 24V DC)
Weight, approx. 0.333 kg (0.73 lb) 0.651 kg (1.44 lb) 1.64 kg (3.62 lb)
Dimensions (HxWxD), approx. 116 x 138 x 43 mm
(4.56 x 5.43 x 1.69 in.)
144 x 197 x 54 mm
(5.67 x 7.75 x 2.13 in.)
225 x 287 x 55 mm
(8.86 x 11.3 x 2.16 in.)
General Specifications
Attribute Value
Wire size Input Power Terminal Block
Stranded or solid, Cu 90 °C (194 °F)
Single-Wire Gauge: 0.33…2.08 mm
2
(22...14 AWG)
Dual-wire Gauge: 0.33…1.31 mm
2
(22…16 AWG)
Wire type Copper
Wiring category
(1)
(1)
Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding Guidelines,
publication 1770-4.1.
3 – on power ports
2 – on communication ports
Enclosure type ratings Meets NEMA/UL Type 4X (indoor) 12, 13, and IP65
North American Temp Code T4A
