Specifications
PanelView Plus and PanelView Plus Compact 400 and 600 Terminals
Attribute Value
Display
400 and 600 grayscale display
400 and 600 color display
Grayscale passive matrix, film compensated super-twist nematic
(FSTN) LCD technology
Color active matrix, thin film transistor (TFT) LCD technology
Display size, Approx., diagonal
400 grayscale display
400 color display
600 grayscale/color display
95 mm (3.7 in.)
89 mm (3.5 in.)
139 mm (5.5 in.)
Display area (WxH), Approx.
400 grayscale display
400 color display
600 grayscale/color display
77 x 58 mm (3.0 x 2.3 in.)
71 x 53 mm (2.8 x 2.1 in.)
112 x 84 mm (4.4 x 3.3 in.)
Display resolution
400 grayscale/color display
600 grayscale/color display
320 x 240
320 x 240
Backlight
400 grayscale/color display
600 grayscale/color display
LED
CCFL 50,000 hours life, min.
Touch Screen
Touch screen Analog resistive
Actuating rating 1 million presses
Operating force 10…110 g
Keypad
Function keys 8 or 10 function, numeric and navigation keys
Actuation rating 1 million presses
Operating force 340 g
Electrical
Input voltage, DC
Power consumption, DC
24V DC nom (18…30V DC)
25 W max (1.0 A @ 24V DC)
Input voltage, AC
Power consumption, AC
85…264V AC, 47…63 Hz
60V A max
