Allen-Bradley POINT I/O series User Manual

POINT I/O 2 and 4 Relay Output Modules 15
Publication 1734-IN055H-EN-E - August 2016
Wire the Module
WARNING: If you connect or disconnect wiring while the field-side power is
on, an electrical arc can occur. This could cause an explosion in hazardous
location installations. Be sure that power is removed or the area is
nonhazardous before proceeding.
Relay
Output
Module
Status
Network
Status
1734
OW4
NODE:
0
1
2
3
Relay
Output
Module
Status
Network
Status
1734
OW2
0
1
NODE:
Module status
Network status
Status of output 0
Status of output 1
C
V
C
V
C = Common
V = Supply
Output 0A
Output 0B
Output 1A
Output 1B
Status of output 2
Status of output 3
Output 0A
Output 0B
Output 1A
Output 1B
Output 2A
Output 2B
Output 3A
Output 3B
45183 45184
1734-OW2 1734-OW4
