Allen-Bradley POINT I/O series User Manual

POINT I/O 2 and 4 Relay Output Modules 7
Publication 1734-IN055H-EN-E - August 2016
Modules Mounted on 1734-TOP or 1734-TOPS One-piece Terminal Base
Description Description
1 Module locking mechanism 5 Interlocking side pieces
2 Slide-in writable label 6 Mechanical keying
3 Handle 7 DIN rail locking screw (orange)
4 1734-TOP or 1734-TOPS one-piece terminal
base with screw or spring clamp
8 Module wiring diagram
1
8
7
6
5
2
3
4
45712
