Allen-Bradley PowerFlex 755TL Product Information

14 PowerFlex 750-Series Products with TotalFORCE Control
Rockwell Automation Publication 750-PC100A-EN-P - December 2016
Supplemental Fuse Kits
This section lists the fuse kits used to protect components.
Fused Disconnect Switch (FD1) Fuse
Input Voltage Frame Size Cat. No. Specification Qty.
400/480/600 8 SK-RM-IBD-FUSEA-F8 Class J - 600V, 30 A 3
690 8 SK-RM-IBD-FUSEB-F8 Class gG - 690V, 32 A 3
400/480 9 SK-RM-IBD-FUSEC-F9 Class J - 600V, 70 A 3
600 9 SK-RM-IBD-FUSED-F9 Class J - 600V, 60 A 3
690 9 SK-RM-IBD-FUSEE-F9 Class gG - 690V, 63 A 3
400/480 10 SK-RM-IBD-FUSEF-F10 Class J - 600V, 110 A 3
600 10 SK-RM-IBD-FUSEG-F10 Class J - 600V, 80 A 3
690 10 SK-RM-IBD-FUSEH-F10 Class gG - 690V, 80 A 3
400/480 11 SK-RM-IBD-FUSEI-F11 Class J - 600V, 150 A 3
600 11 SK-RM-IBD-FUSEF-F10 Class J - 600V, 110 A 3
690 11 SK-RM-IBD-FUSEJ-F12 Class gG - 690V, 125 A 3
400/480 12 SK-RM-IBD-FUSEK-F12 Class J - 600V, 200 A 3
600 12 SK-RM-IBD-FUSEI-F11 Class J - 600V, 150 A 3
690 12 SK-RM-IBD-FUSEL-F12 Class gG - 690V, 160 A 3
Control Board (FH1) Fuse
Input Voltage Frame Size Cat. No. Specification Qty.
400/480/600 8…12 SK-RM-IBCB-FUSE1A-F8 Class J - 600V, 1 A 3
690 8…12 SK-RM-IBCB-FUSE1B-F9 Class gG - 690V 1 A 3
Control Transformer 240V Secondary Distribution (FH2) Fuse
Input Voltage Frame
Size
Enclosure
Type
Cat. No. Specification Qty.
400/480/600 8 IP21
UL Type1
SK-RM-IBFH2-FUSE2A-F8 Class J - 600V, 15 A 1
690 8 IP21
UL Type1
SK-RM-IBFH2-FUSE2B-F8 Class gG - 500V, 16 A 1
400/480/600 8 IP54
UL Type12
SK-RM-IBFH2-FUSE2C-F8 Class J - 600V, 20 A 1
690 8 IP54
UL Type12
SK-RM-IBFH2-FUSE2D-F8 Class gG - 500V, 20 A 1
400/480/600 9 IP21
UL Type1
SK-RM-IBFH2-FUSE2E-F9 Class J - 600V, 25 A 1
690 9 IP21
UL Type1
SK-RM-IBFH2-FUSE2F-F9 Class gG - 400V, 25 A 1
400/480/600 9 IP54
UL Type12
SK-RM-IBFH2-FUSE2G-F9 Class J - 600V, 35 A 1
690 9 IP54
UL Type12
SK-RM-IBFH2-FUSE2H-F9 Class gG - 690V, 40 A 1
400/480/600 10 IP21
UL Type1
SK-RM-IBFH2-FUSE2G-F9 Class J - 600V, 35 A 1
690 10 IP21
UL Type1
SK-RM-IBFH2-FUSE2H-F9 Class gG - 690V, 40 A 1
400/480/600 10 IP54
UL Type12
SK-RM-IBFH2-FUSE2I-F10 Class J - 600V, 60 A 1
690 10 IP54
UL Type12
SK-RM-IBFH2-FUSE2J-F10 Class gG - 690V, 63 A 1
400/480/600 11 IP21
UL Type1
SK-RM-IBFH2-FUSE2K-F11 Class J - 600V, 45 A 1
690 11 IP21
UL Type1
SK-RM-IBFH2-FUSE2L-F11 Class gG - 690V, 50 A 1
400/480/600 11 IP54
UL Type12
SK-RM-IBFH2-FUSE2M-F11 Class J - 600V, 70 A 1
690 11 IP54
UL Type12
SK-RM-IBFH2-FUSE2N-F11 Class gG - 690V, 80 A 1
400/480/600 12 IP21
UL Type1
SK-RM-IBFH2-FUSE2I-F10 Class J - 600V, 60 A 1
690 12 IP21
UL Type1
SK-RM-IBFH2-FUSE2P-F12 Class gG - 690V, 63 A 1
400/480/600 12 IP54
UL Type12
SK-RM-IBFH2-FUSE2O-F12 Class J - 600V, 90 A 1
690 12 IP54
UL Type12
SK-RM-IBFH2-FUSE2P-F12 Class gG - 500V 100 A 1
Control Transformer 240V Secondary Distribution (FH3) Fuse
Input Voltage Frame Size Cat. No. Specification Qty.
690 8…9 SK-RM-IBFH3-FUSE3A-F8 Class gG - 500V, 2 A 1
400/480/600 8…9 SK-RM-IBFH3-FUSE3B-F8 Class CC - 500V, 2 A 1
690 10…12 SK-RM-IBFH3-FUSE3C-F10 Class gG - 500V, 4 A 1
400/480/600 10…12 SK-RM-IBFH3-FUSE3D-F10 Class CC - 500V, 4 A 1
Control Transformer Primary (FH4…7) Fuse
Input Voltage Frame
Size
Enclosure
Type
Cat. No. Specification Qty.
400/480/600 8 IP21
UL Type1
SK-RM-IBFH4-FUSE4A-F8 Class J - 600V, 20 A 2
690 8 IP21
UL Type1
SK-RM-IBFH4-FUSE4B-F8 Class gG - 690V, 16 A 2
400/480/600 8 IP54
UL Type12
SK-RM-IBFH4-FUSE4C-F8 Class J - 600V, 30 A 2
690 8 IP54
UL Type12
SK-RM-IBFH4-FUSE4D-F8 Class gG - 690V, 20 A 2
400/480/600 9 IP21
UL Type1
SK-RM-IBFH4-FUSE4C-F8 Class J - 600V, 30 A 2
690 9 IP21
UL Type1
SK-RM-IBFH4-FUSE4D-F8 Class gG - 690V, 20 A 2
400/480/600 9 IP54
UL Type12
SK-RM-IBFH4-FUSE4F-F9 Class J - 600V, 30 A 2
690 9 IP54
UL Type12
SK-RM-IBFH4-FUSE4H-F9 Class gG - 690V, 20 A 2
400/480/600 10 IP21
UL Type1
SK-RM-IBFH4-FUSE4F-F9 Class J - 600V, 30 A 2
690 10 IP21
UL Type1
SK-RM-IBFH4-FUSE4H-F9 Class gG - 690V, 20 A 2
400/480/600 10 IP54
UL Type12
SK-RM-IBFH4-FUSE4F-F9 Class J - 600V, 30 A 2
690 10 IP54
UL Type12
SK-RM-IBFH4-FUSE4H-F9 Class gG - 690V, 20 A 2
400/480/600 11 IP21
UL Type1
SK-RM-IBFH4-FUSE4I-F10 Class J - 600V, 30 A 2
690 11 IP21
UL Type1
SK-RM-IBFH4-FUSE4H-F9 Class gG - 690V, 20 A 2
400/480/600 11 IP54
UL Type12
SK-RM-IBFH4-FUSE4J-F11 Class J - 600V, 30 A 2
690 11 IP54
UL Type12
SK-RM-IBFH4-FUSE4K-F11 Class gG - 690V, 20 A 2
400/480/600 12 IP21
UL Type1
SK-RM-IBFH4-FUSE4J-F11 Class J - 600V, 30 A 2
690 12 IP21
UL Type1
SK-RM-IBFH4-FUSE4K-F11 Class gG - 690V, 20 A 2
400/480/600 12 IP54
UL Type12
SK-RM-IBFH4-FUSE4L-F12 Class J - 600V, 30 A 2
690 12 IP54
UL Type12
SK-RM-IBFH4-FUSE4M-F12 Class gG - 690V, 20 A 2
Control Transformer 240V Secondary Distribution (FH2) Fuse (continued)
Input Voltage Frame
Size
Enclosure
Type
Cat. No. Specification Qty.
