6. Press the START (enter) keypad when the correct value ap-
pears in the display. The new value is saved and the next op-
tion will appear in the display.
Default Cycle dFtCyC
This option allows the owner to set the default cycle that the ma-
chine will enter when in the Ready Mode.
1. Control must be in Manual Mode. Refer to How to Enter the
Manual Mode.
2. Press the DELICATES (∧) or the COLD (∨) keypad until
Prog appears in the display. Press the START (enter) keypad,
and AtS 1 will appear in the display.
3. Press the DELICATES (∧) or the COLD (∨) keypad to scroll
through the programmable options until dFtCyC appears in
the display.
4.
When dFtCyC appears in the display, press the START (en-
ter) keypad. A number will appear in the display. Refer to ta-
ble below. This number corresponds to the current default cy-
cle value. The corresponding LEDs will also be lit.
Cycle Number on Display
NORMAL/ HOT 1
NORMAL/ WARM 2
NORMAL/ COLD 3
PERM PRESS/ HOT 4
PERM PRESS/ WARM 5
PERM PRESS/ COLD 6
DELICATES/ HOT 7
DELICATES/ WARM 8
DELICATES/ COLD 9
Table 3
5. Press the DELICATES (∧) or the COLD (∨) keypad to in-
crease or decrease the current number to the desired number.
6. Press the START (enter) keypad when the correct value ap-
pears in the display. The new value is saved and the next op-
tion will appear in the display.
Card Reader Display Control CArd
This option allows the owner to program whether the display is
controlled by the machine’s electronic control or an external pay-
ment system such as a card reader.
NOTE: This feature does not need to be programmed
manually. The card reader itself makes this determina-
tion.
1. Control must be in Manual Mode. Refer to How to Enter the
Manual Mode.
2. Press the DELICATES (∧) or the COLD (∨) keypad until
Prog appears in the display. Press the START (enter) keypad,
and AtS 1 will appear in the display.
3. Press the DELICATES (∧) or the COLD (∨) keypad to scroll
through the programmable options until CArd appears in the
display.
4.
When CArd appears in the display, press the START (enter)
keypad. The current Card Reader Display Control Status will
appear in the display.
on = Card Reader/External Payment System controls display
oFF = Machine Electronic Control controls display (factory de-
fault setting)
5. Press the DELICATES (∧) or the COLD (∨) keypad to change
the current status.
6. Press the START (enter) keypad when the correct value ap-
pears in the display. The new value is saved and the next op-
tion will appear in the display.
Audio Signal AUdio
This option allows the owner to program when the signal will
sound.
There are five occasions when a signal may sound during the
washer operation. These five occasions are listed below:
1. End of Cycle Signal By default, the signal is turned off. If
turned on, the signal will sound for three seconds at the end of
a cycle.
2. Keypad Depression Signal By default, this signal is turned
on and will sound for a quarter of a second. This signal will
sound each time a keypad is pressed.
3. Coin Input/Card Insertion Signal By default, this signal is
turned on and will sound for a quarter of a second each time a
coin or card is entered.
4. Remove Card Signal (Card Models Only) By default, this
signal is turned on and will sound one second on and one sec-
ond off when the control is prompting for card removal.
5. Signal for Start By default, this signal is turned on and will
sound one second on and one second off for 10 seconds after
vend price has been satisfied.
How to Program the Audio Signal
1. Control must be in Manual Mode. Refer to How to Enter the
Manual Mode.
2. Press the DELICATES (∧) or the COLD (∨) keypad until
Prog appears in the display. Press the START (enter) keypad,
and AtS 1 will appear in the display.
3. Press the DELICATES (∧) or the COLD (∨) keypad to scroll
through the programmable options until AUdio appears in the
display.
4.
When AUdio appears in the display press the START (enter)
keypad. A number will appear in the display. This number
corresponds to the current Audio Signal Programming Value.
Programming Control
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
42 Part No. 204370ENR1
