79
9.3 IR Board
715G6077R01000004K (32”)
R204
100R 1/10W 5%
R0603
VCC
9mm
35mm
CN201
CON201
1
2
3
4
5
67
U201
IRM-H938M3/TR2
GND
1
GND
2
OUT
3
VCC
4
IR
VCC
R201
15K 1/10W
081G 14 24 EL
R203 220 OHM 1/10W
LED_B
LED_R
RED
BLUE
LED201
LED
1
23
4
R202 220 OHM 1/10W
356GS927057
311GW125D05ACX
C201
2.2UF 16V
