13
Luminance
Luminance
Color Setup Picture Boost OSD Setup ExitExtra
Contrast 50
Brightness 90
Eco Mode Standard
Gamma Gamma 1
DCR Off
HDR Mode Off
Game Setting
PIP Setting
PIP
Contrast 0-100 Contrast from Digital-register.
Brightness 0-100 Backlight Adjustment
Eco mode
Standard
Standard Mode
Text
Text Mode
Internet
Internet Mode
Game
Game Mode
Movie
Movie Mode
Sports
Sports Mode
Reading
Reading Mode
Uniformity
Uniformity Mode
Gamma
Gamma1 Adjust to Gamma 1
Gamma2 Adjust to Gamma 2
Gamma3 Adjust to Gamma 3
DCR
Off Disable dynamic contrast ratio
On
Enable dynamic contrast ratio
HDR Mode
OFF
Adjust HDR Mode.
HDR Picture
HDR Movie
HDR Game
Note:
When “HDR Mode” is set to a non-off state, “Contrast”, “Brightness Scene Mode”, and “Gamma” items cannot be
adjusted.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the AOC U27P2CA and is the answer not in the manual?

AOC U27P2CA Specifications

General IconGeneral
Color depth10 bit
Pixel pitch0.1554 x 0.1554 mm
Screen shapeFlat
Pixel density1638 ppi
Backlight typeW-LED
Display surfaceMatt
Display diagonal27 \
Surface hardness3H
Anti-glare screenYes
Adobe RGB coverage81 %
Display technologyLED
Native aspect ratio16:9
Maximum refresh rate60 Hz
Horizontal scan range30 - 140 kHz
Supported video modes2160p
Viewable size, vertical335.664 mm
sRGB coverage (typical)112 %
Contrast ratio (dynamic)50000000:1
Contrast ratio (typical)1000:1
Display number of colors1.07 billion colors
Display diagonal (metric)68.6 cm
Viewable size, horizontal596.736 mm
Display scanning frequencyHDMI 2.0/DP 1.2: 30-140 KHz (H), HDMI 2.0/DP 1.2: 23 - 75 Hz (V)
Display brightness (typical)350 cd/m²
Supported graphics resolutions3840 x 2160
USB hub version3.2 Gen 1 (3.1 Gen 1)
DisplayPort version1.2
Headphone connectivity3.5 mm
USB Power Delivery up to65 W
VGA (D-Sub) ports quantity0
USB Type-A downstream ports quantity4
Tilt angle range-5 - 35 °
Height adjustment150 mm
Cable lock slot typeKensington
Number of OSD languages16
Panel mounting interface100 x 100 mm
On Screen Display (OSD) languagesCHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, POL, POR, RUS, SWE
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (max)75 W
Power consumption (off)0.3 W
Power consumption (standby)0.5 W
Power consumption (typical)37 W
RMS rated power2 W
CertificationISO
Product colorBlack
Heavy metals freeHg (mercury)
Market positioningBusiness
CompatibilityVESA-P2
Operating altitude0 - 5000 m
Non-operating altitude0 - 12192 m
Storage temperature (T-T)-25 - 55 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 93 %
Operating relative humidity (H-H)10 - 85 %
Cables includedAudio (3.5mm), DisplayPort, HDMI
Audio cable length1.8 m
Package typeBox
Package depth160 mm
Package width690 mm
Package height595 mm
Package weight9600 g
Sustainability certificatesWEEE
Exterior finish typeTextured
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)200.1 mm
Width (with stand)613.6 mm
Height (with stand)544.5 mm
Weight (with stand)7100 g
Depth (without stand)51.1 mm
Height (without stand)369.5 mm
Weight (without stand)5100 g
