Arcam AVR550 Custom Installation Notes

5
System Command Specifications
Power (0x00)
Request the stand-by state of a zone.
Example
Command/response sequence to request the power state of zone 1 where
zone 1 has power on:
Command: 0x21 0x01 0x00 0x01 0xF0 0x0D
Response: 0x21 0x01 0x00 0x00 0x01 0x01 0x0D
Display Brightness (0x01)
Request the brightness of the front panel display.
Example
Command/response sequence for requesting the brightness of the display
where the display is o:
Command: 0x21 0x01 0x01 0x01 0xF0 0x0D
Response: 0x21 0x01 0x01 0x00 0x01 0x00 0x0D
Headphones (0x02)
Determine whether headphones are connected.
Example
Command/response sequence to request the headphone status where the
headphones are not connected:
Command: 0x21 0x01 0x02 0x01 0xF0 0x0D
Response: 0x21 0x01 0x02 0x00 0x01 0x00 0x0D
COMMAND:
Byte: Description:
St 0x21
Zn 0x01
Cc 0x02
Dl 0x01
Data 0xF0 – Request current headphone connection status
Et 0x0D
RESPONSE:
Byte: Description:
St 0x21
Zn 0x01
Cc 0x02
Ac Answer code
Dl 0x01 (Data length)
Data 0x00 – Headphones are not connected.
0x01 – Headphones are connected
Et 0x0D
COMMAND:
Byte: Description:
St 0x21
Zn 0x01
Cc 0x01
Dl 0x01
Data 0xF0 – Request brightness
Et 0x0D
RESPONSE:
Byte: Description:
St 0x21
Zn 0x01
Cc 0x01
Ac Answer code
Dl 0x01
Data 0x00 – Front panel is off
0x01 – Front panel L1
0x02 – Front panel L2
Et 0x0D
COMMAND:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x00
Dl 0x01
Data 0xF0 – Request power state
Et 0x0D
RESPONSE:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x00
Ac Answer code
Dl 0x01
Data 0x00 – Zone is in stand-by
0x01 – Zone is powered on
Et 0x0D

Arcam AVR550 Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	110 dB
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	7
Ethernet LAN (RJ-45) ports	1
Number of HDMI outputs	3
AirPlay	No
Audio decoders	DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD Master Audio
Audio Return Channel (ARC)	Yes
Apple docking compatibility	Not supported
Power consumption (standby)	0.5 W
Power consumption (typical)	1500 W
Supported radio bands	DAB, DAB+, FM
Internet radio services supported	Spotify
12V trigger ports quantity	2
Speakers connectivity type	-
Package weight	18800 g

Weight and Dimensions

Depth	425 mm
Width	433 mm
Height	171 mm
Weight	15500 g
