Arcam AVR550 Custom Installation Notes

8
Display Information Type (0x09)
Set the VFD display information type (where applicable).
e return data echoes the data sent.
Example
Command/response sequence to set the display text to show the current FM
radio text with FM playing in zone 2:
Command: 0x21 0x02 0x09 0x01 0x01 0x0D
Response: 0x21 0x02 0x09 0x00 0x01 0x01 0x0D
COMMAND:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x09
Dl 0x01
Data For all sources:
0x00 – Set the display to Processing mode
0xE0 – Cycle though all displayable information.
0xF0 – Request the current display type
If the current source is FM:
0x01 – Set the display to Radio text
0x02 – Set the display to Programme type
0x03 – Set the display to Signal strength
If the current source is DAB (AVR450/750 only):
0x01 – Set the display to Radio text
0x02 – Set the display to Genre
0x03 – Set the display to Signal quality
0x04 – Set the display to Bit rate
If the current source is NET/USB
0x01 – Set the display to Track
0x02 – Set the display to Artist
0x03 - Set the display to Album
0x04 – Set the display to audio type
0x05 – Set the display to rate
Et 0x0D
RESPONSE:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x09
Ac Answer code
Dl 0x01
Data The current display is returned, as for the command.
Et 0x0D

Arcam AVR550 Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	110 dB
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	7
Ethernet LAN (RJ-45) ports	1
Number of HDMI outputs	3
AirPlay	No
Audio decoders	DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD Master Audio
Audio Return Channel (ARC)	Yes
Apple docking compatibility	Not supported
Power consumption (standby)	0.5 W
Power consumption (typical)	1500 W
Supported radio bands	DAB, DAB+, FM
Internet radio services supported	Spotify
12V trigger ports quantity	2
Speakers connectivity type	-
Package weight	18800 g

Weight and Dimensions

Depth	425 mm
Width	433 mm
Height	171 mm
Weight	15500 g
