Ariel JGJ Series User Manual

FOR MODELS: JGW, JGR AND JGJ SECTION 5 - MAINTENANCE
1/01 PAGE 5 - 17
11. Re-attach all tubing to the lubricator.
FIGURE 5-10: FORCE FEED LUBRICATOR AND SPROCKET - TYPICAL
Oil O-Ring
Before
Assembly
Drain PlugDrain to Crankcase
or to an Appropriate
Drain System
Sight Glass
Sintered
Bronze
Filter
1/4-Inch Tubing
Connection for a
Priming Pump
Priming
Stem
Pump Outlet to
Distribution Block
Locknut
Lubricator
Oil Fill
Connection
Sprocket
No. 204
Woodruff
Key
Setscrew
Sprocket
Face-to-Face
Thickness
