FOR MODELS: JGW, JGR AND JGJ SECTION 4 - LUBRICATION AND VENTING
1/01 PAGE 4 - 17
FIGURE 4-6: OIL HEAD TRAP FITTING
FIGURE 4-7: FORCE FEED LUBRICATION SYSTEM SCHEMATIC - TYPICAL
DNFT-Digital No-Flow
Timer Shutdown Switch
To Other Cylinders
and Packings
Sintered
Bronze
Filter
Blow-Out
Disc
Compressor
Frame-Oil
Gallery
Force Feed
Lubricator
Pump
Drain to
Crankcase
Single Ball
Check Valve
Double Ball
Check Valve
Bottom Cylinder
Injection Point
Packing
Injection
Point
Single Ball
Check Valve
Divider Valves
Distribution
Block
Pressure Gauge
Top Cylinder
Injection Point
To Check Valve
To Lube Point
