Ariens Edge Series User Manual

EN - 11
HOUR METER
Hour meter measure engine runtime and
cannot be reset.
HEIGHT-OF-CUT ADJUSTMENT
SYSTEM
See Figure 9.
Sets the height of cut.
DECK LIFT PEDAL
Raises mower deck to change height-of-cut
setting.
SEAT ADJUSTMENT LEVER
Unlocks seat to allow operator to move seat
forward or backward and then lock in desired
position.
PARKING BRAKE LEVER
See Figure 10.
Controls the parking brake. The engine will
not start with brake in the off position.
SAFETY INTERLOCK SYSTEM
Monitors the interaction of various unit
features for operator safety.
STEERING LEVERS
Control the direction and speed of unit. To
stop unit, return both steering levers to
neutral.
TRANSAXLE BYPASS LEVERS
Control the transaxles so unit may be moved
with the engine off.
Figure 8
Blades Off
Blades On
Figure 9
Parking Brake
Engaged (On)
Brake Released
(Off)
Figure 10
