Ariston E-Combi 24 Installation And Servicing Instructions

maintenance guide
44
Tools Time
5 min
1
NTC1
NTC2
NTC1 : Black wires
NTC2 : Grey wires
Unplug the electrical connectors Remove the clip and the temperature sensor
TEMPERATURE (°C) RESISTANCE (kOmh)
027
10 17
20 12
25 10
30 8
40 5
50 4
60 3
70 2
80 1,5
Tools Time
5 min
1
Drain boiler (see 3.3). Remove the second
clip and pull the assembly toward you
Push on the by-pass to disengage it
By-Pass Assembly
Temperature Sensor
