2000 SERIES SENSORS INSTALLATION GUIDE Revision 3.1 June 1997
SUITABLE LOCATIONS FOR SMOKE & HEAT DETECTORS
General rule : ION : Flaming Fire
OPTICAL : Smouldering Fire
HEAT : Full Combustion Fire
LOCATION ION OP
T
HEAT REMARKS
Corridor / Walkway # Air current may exist
Elevator Shaft / Duct # Air current is present
General Office / Day Room #
Hotel Foyer #
Dining Room #
Theatre Stages / Audience
Hall
#
Warehouse # Not if diesel fork lifts
are used
School #
Clinic / Nursery Room #
Laboratory #
Studio / Recording Room # Possibility of flaming
fire
Factory #
Church / Chapel #
Cargo Handling Area # Presence of air current
& dust
Spirit Fuel Store # Fast, clean burning fire
Library Room #
Central Heating Room #
Dryer Room #
Kitchen # Avoid locations over
ovens
Smoky Atmosphere #
Closed Parking Area #(1) # (1) : delayed or double
knock
2.2.2 Mounting Bases & Wiring Diagrams
All connectors on the base are numbered and have the following function:
1 : (+) remote LED
2 : (-) remote LED
5 : (+) line in and out
6 : (-) line in and out
Earth : to continue ground shield
