English
29
X570 Creator
2.4 Expansion Slots (PCI Express Slots)
ere are 6 PCI Express slots on the motherboard.
PCIe slots:
PCIE1 (PCIe 4.0 x16 slot) is used for PCI Express x16 lane width graphics cards.
PCIE2 (PCIe 2.0 x1 slot) is used for PCI Express x1 lane width cards.
PCIE3 (PCIe 2.0 x1 slot) is used for PCI Express x1 lane width cards.
PCIE4 (PCIe 4.0 x16 slot) is used for PCI Express x8 lane width graphics cards.
PCIE5 (PCIe 2.0 x1 slot) is used for PCI Express x1 lane width cards.
PCIE6 (PCIe 4.0 x16 slot) is used for PCI Express x4 lane width graphics cards.
PCIe Slot Congurations
Ryzen series CPUs (Matisse):
Before installing an expansion card, please make sure that the power supply is switched o
or the power cord is unplugged. Please read the documentation of the expansion card and
make necessary hardware settings for the card before you start the installation.
PCIE1 PCIE4 PCIE6
Single Graphics Card Gen4x16 N/A N/A
Two Graphics Cards in
CrossFireX
TM
or SLI
TM
Mode
Gen4x8 Gen4x8 N/A
ree Graphics Cards in
3-Way CrossFireX
TM
Mode
Gen4x8 Gen4x8 Gen4x4
