ASROCK X570 Taichi User Manual

English
3
X570 Taichi Razer Edition
* For Ryzen Series APUs (Picasso), ECC is only supported with
PRO CPUs.
* Please refer to Memory Support List on ASRock’s website for
more information. (http://www.asrock.com/)
* Please refer to page 25 for DDR4 UDIMM maximum
frequency support.
•
Max. capacity of system memory: 128GB
•
Supports Extreme Memory Prole (XMP) memory modules
•
15μ Gold Contact in DIMM Slots
Expansion
Slot
AMD Ryzen series CPUs (Vermeer)
•
3 x PCI Express x16 Slots (PCIE1/PCIE3/PCIE4: single at
Gen4x16 (PCIE1); dual at Gen4x8 (PCIE1) / Gen4x8 (PCIE3);
triple at Gen4x8 (PCIE1) / Gen4x8 (PCIE3) / Gen4x4
(PCIE4))*
AMD Ryzen series CPUs (Matisse)
•
3 x PCI Express x16 Slots (PCIE1/PCIE3/PCIE4: single at
Gen4x16 (PCIE1); dual at Gen4x8 (PCIE1) / Gen4x8 (PCIE3);
triple at Gen4x8 (PCIE1) / Gen4x8 (PCIE3) / Gen4x4
(PCIE4))*
AMD Ryzen series APUs (Renoir)
•
3 x PCI Express x16 Slots (PCIE1/PCIE3/PCIE4: single at
Gen3x16 (PCIE1); dual at Gen3x8 (PCIE1) / Gen3x8 (PCIE3);
triple at Gen3x8 (PCIE1) / Gen3x8 (PCIE3) /
•
Gen4x4 (PCIE4))*
AMD Ryzen series CPUs (Pinnacle Ridge)
•
3 x PCI Express x16 Slots (PCIE1/PCIE3/PCIE4: single at
Gen3x16 (PCIE1); dual at Gen3x8 (PCIE1) / Gen3x8 (PCIE3);
triple at Gen3x8 (PCIE1) / Gen3x8 (PCIE3) / Gen4x4
(PCIE4))*
AMD Ryzen series APUs (Picasso)
•
1 x PCI Express 3.0 x16 Slot (single at x8 (PCIE1))*
•
1 x PCI Express 4.0 x16 Slot (single at x4 (PCIE4))*
* Supports NVMe SSD as boot disks
•
1 x PCI Express 4.0 x1 Slot

ASROCK X570 Taichi Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Audio chip	Realtek ALC1220
Certification	FCC, CE, ErP/EuP ready
Component for	PC
Motherboard chipset	AMD X570
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 x64
ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2400, 2667, 2933, 3200, 3466, 4133, 4200, 4266, 4300, 4400 MHz
BIOS type	UEFI AMI
ACPI version	5.1
BIOS memory size	256 Mbit
System Management BIOS (SMBIOS) version	2.3
Graphics card	Radeon Vega
DirectX version	12.0
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	-
PS/2 ports quantity	1
WiFi-AP antenna jack	2
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
LAN controller	Intel® I211-AT
Wi-Fi standards	802.11a, 802.11ad, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.0
Ethernet interface type	Gigabit Ethernet
Number of M.2 (M) slots	3
Number of SATA III connectors	8
Bundled software	Software - ASRock Polychrome SYNC - ASRock XFast LAN UEFI - ASRock Full HD UEFI - ASRock Instant Flash - ASRock Easy RAID Installer
Supported storage drive interfaces	PCI Express 3.0, SATA III
Harmonized System (HS) code	84733020
Weight	1500 g

Weight and Dimensions

Depth	244 mm
Width	305 mm
Height	350 mm
