5-225-22
5-225-22
5-22
Chapter 5: Software supportChapter 5: Software support
Chapter 5: Software supportChapter 5: Software support
Chapter 5: Software support
5.5.15.5.1
5.5.15.5.1
5.5.1
Installing hard disksInstalling hard disks
Installing hard disksInstalling hard disks
Installing hard disks
The motherboard supports Ultra DMA /133/100/66 and Serial ATA hard
disk drives. For optimal performance, install identical drives of the same
model and capacity when creating a disk array.
Installing Parallel ATA hard disksInstalling Parallel ATA hard disks
Installing Parallel ATA hard disksInstalling Parallel ATA hard disks
Installing Parallel ATA hard disks
To install IDE hard disks for a RAID configuration:
1. Set the jumpers of each hard disk as Master/Master or Slave/Slave.
2. Install the hard disks into the drive bays.
3. Connect the HDD signal cables.
4. Connect a 4-pin power cable to the power connector on each drive.
Installing Serial ATA (SATA) hard disksInstalling Serial ATA (SATA) hard disks
Installing Serial ATA (SATA) hard disksInstalling Serial ATA (SATA) hard disks
Installing Serial ATA (SATA) hard disks
To install the SATA hard disks for a RAID configuration:
1. Install the SATA hard disks into the drive bays.
2. Connect the SATA signal cables.
3. Connect a SATA power cable to the power connector on each drive.
If you want to boot the system from a hard disk drive included in a RAID
set, copy first the RAID driver from the support CD to a floppy disk
before you install an operating system to a selected hard disk drive.
Refer to section “5.6 Creating a RAID driver disk” for details.
Refer to the RAID controllers user manual in the motherboard support
CD for detailed information on RAID configurations. See section “5.2.4
Manuals menu”.
