Primary and Secondary IDE Master/SlavePrimary and Secondary IDE Master/Slave
Primary and Secondary IDE Master/SlavePrimary and Secondary IDE Master/Slave
Primary and Secondary IDE Master/Slave
While entering Setup, the BIOS automatically detects the presence of IDE
devices. There is a separate sub-menu for each IDE device. Select a device
item then press <Enter> to display the IDE device information.
The BIOS automatically detects the values opposite the dimmed items
(Capacity, Cylinder, Head, Sector and Transfer Mode). These values are not
user-configurable. These items show N/A if no IDE device is installed in the
system.
PIO ModePIO Mode
PIO ModePIO Mode
PIO Mode
Sets the PIO mode for the IDE device.
Configuration options: [Auto] [Mode 0] [Mode 1] [Mode 2] [Mode 3]
[Mode 4]
UDMA ModeUDMA Mode
UDMA ModeUDMA Mode
UDMA Mode
Disables or sets the UDMA mode. Configuration options: [Disabled] [Auto]
IDE Primary Master/Slave [Auto]; IDE Secondary Master/IDE Primary Master/Slave [Auto]; IDE Secondary Master/
IDE Primary Master/Slave [Auto]; IDE Secondary Master/IDE Primary Master/Slave [Auto]; IDE Secondary Master/
IDE Primary Master/Slave [Auto]; IDE Secondary Master/
Slave [Auto]Slave [Auto]
Slave [Auto]Slave [Auto]
Slave [Auto]
Select [Auto] to automatically detect an IDE hard disk drive. If automatic
detection is successful, the BIOS automatically fills in the correct values for
the remaining fields on this sub-menu. If the hard disk was already
formatted on a previous system, the setup BIOS may detect incorrect
parameters. Select [Manual] to manually enter the IDE hard disk drive
parameters. If no drive is installed select [None].
Configuration options: [None] [Auto] [Manual]
F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select Sub-menu F10: Save and Exit
Phoenix-Award BIOS CMOS Setup Utility
Main
Select Menu
Item Specific Help
Press [Enter] to
select
Primary IDE Master
PIO Mode [Auto]
UDMA Mode [Auto]
Primary IDE Master [Auto]
Access Mode [Auto]
UDMA Mode [Auto]
Capacity 13579 MB
Cylinder 26310
Head 16
Sector 63
Transfer Mode UDMA 4
