Asus A8N-SLI DLX User Manual

ASUS A8N-SLI DeluxeASUS A8N-SLI Deluxe
ASUS A8N-SLI DeluxeASUS A8N-SLI Deluxe
ASUS A8N-SLI Deluxe
4-214-21
4-214-21
4-21
DRAM ConfigurationDRAM Configuration
DRAM ConfigurationDRAM Configuration
DRAM Configuration
The items in this sub-menu show the DRAM-related information
auto-detected by the BIOS.
F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select Sub-menu F10: Save and Exit
Select Menu
Item Specific Help
Place an artificial
memory clock limit on
the system. Memory is
prevented from
running faster than
this frequency.
DRAM Configuration
Max Memclock (MHz) [Auto]
1T/2T Memory Timing [Auto]
CAS# latency (Tcl) [Auto]
RAS# to CAS# delay (Trcd) [Auto]
Min RAS# active time (Tras) [Auto]
Row precharge Time (Trp) [Auto]
Master ECC Enabled [Disabled]
Phoenix-Award BIOS CMOS Setup Utility
Advanced
Max Memclock (MHz) [Auto]
Sets the maximum operating memory clock.
Configuration options: [Auto] [DDR200] [DDR266] [DDR333]
[DDR400] [DDR400] [DDR433] [DDR466] [DDR500] [DDR533]
[DDR550] [DDR600]
1T/2T Memory Timing [Auto]
Sets the memory timing. Configuration options: [Auto] [1T] [2T]
CAS# latency (Tcl) [Auto]
Sets the CAS# latency.
Configuration options: [Auto] [2.0] [2.5] [3.0]
RAS# to CAS# delay (Trcd) [Auto]
Sets the RAS# to CAS# delay to Rd/Wr command on the same bank.
Configuration options: [Auto] [2] [3] [4] [5] [6] [7]
Min RAS# active time (Tras) [Auto]
Sets the minimum RAS# active time.
Configuration options: [Auto] [5] [6] [7] [8] [9] [10] [11] [12] [13]
[14] [15]

Asus A8N-SLI DLX Specifications

General

Chipset	NVIDIA nForce4 SLI
Socket	Socket 939
Form Factor	ATX
Memory Type	DDR
Memory Slots	4
Maximum Memory	4 GB
PCI Express x16 Slots	2
PCI Slots	3
SATA Ports	4
IDE Ports	2
LAN	Gigabit Ethernet
Expansion Slots	2 x PCIe x16, 3 x PCI
USB Ports	10 x USB 2.0
