Asus Eee PC 900 User Manual

2-8 Chapter 2: Knowing the Parts
1
2 3 4
Left Side
Refer to the following illustration to identify the components on this
side of the Eee PC.
LAN Port
The eight-pin RJ-45 LAN port (10/100M bit) supports a
standard Ethernet cable for connection to a local network.
The built-in connector allows convenient use without
additional adapters.
2.0
USB Port (2.0/1.1)
The USB (Universal Serial Bus) port is compatible with USB
2.0 or USB 1.1 devices such as keyboards, pointing devices,
cameras, and storage devices, connected in a series up to
12Mbits/sec (USB 1.1) and 480Mbits/sec (USB 2.0). USB
allows many devices to run simultaneously on a single
computer, with some peripherals acting as additional plug-
in sites or hubs. Also, it supports hot-swapping function.
Microphone Jack
The microphone jack is designed to connect the
microphone used for Skype, voice narrations, or simple
audio recordings.
Headphone Output Jack
The 1/8” stereo headphone jack (3.55mm) connects the Eee
PC’s audio out signal to amplified speakers or headphones.
Using this jack automatically disables the built-in speakers.
1
2
3
4

Asus Eee PC 900 Specifications

General

Processor family	Intel® Celeron® M
Processor frequency	0.9 GHz
Processor manufacturer	Intel
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
SSD capacity	16 GB
Card reader integrated	Yes
Display diagonal	8.9 \
Display resolution	1024 x 600 pixels
Native aspect ratio	5:3
Graphics card	GMA 900
Wireless technology	802.11b/g
Audio system	HD Audio
Front camera resolution (numeric)	1.3 MP
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Networking features	Fast Ethernet, WLAN
Operating system installed	Windows XP Home Edition
Product type	Netbook
Product color	Black
Battery life (max)	0 h
Pointing device	Touchpad
AC adapter power	36 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output voltage	12 V

Weight and Dimensions

Depth	170 mm
Width	225 mm
Height	34 mm
Weight	990 g
