Product introduction
1
Motherboard overview
• Unplugthepowercordfromthewallsocketbeforetouchinganycomponent.
• Beforehandlingcomponents,useagroundedwriststraportouchasafelygrounded
objectorametalobject,suchasthepowersupplycase,toavoiddamagingthemdue
tostaticelectricity.
• Beforeyouinstallorremoveanycomponent,ensurethattheATXpowersupplyis
switchedofforthepowercordisdetachedfromthepowersupply.Failuretodoso
maycauseseveredamagetothemotherboard,peripherals,orcomponents.
• Unplugthepowercordbeforeinstallingorremovingthemotherboard.Failuretodoso
cancauseyouphysicalinjuryanddamagetomotherboardcomponents.
Place this
side towards
the rear of the
chassis
ScantheQRcodetogetthedetailedpindenitions.
H110M-CS
PCIEX16
PCIEX1_2
PCIEX1_1
CLRTC
CHASSIS
SPEAKER
USB910
TPM
COM
USB3_12
AAFP
F_PANEL
ATX12V
EATXPWR
CPU_FAN
CHA_FAN
BATTERY
Super
I/O
RTD
2168
ALC
887
Realtek
8111H
DIGI
+VRM
LGA1151
Intel
®
H110
DDR4 DIMM_A1 (64bit, 288-pin module) DDR4 DIMM_B1 (64bit, 288-pin module)
SATA6G_4
SATA6G_2 SATA6G_1
SATA6G_3
128Mb
BIOS
21.08cm(8.3in)
17.78cm(7.0in)
AUDIO
LAN_USB56
USB78
USB3_34
KBMS
VGA
LPT
21 53 4
2
9 810
6
7
12 11
13
6
14
15
16
17

Asus H110M-CS Specifications

General

Form Factor	Micro ATX
Chipset	Intel H110
Socket	LGA 1151
Memory Slots	2 x DIMM
Maximum Memory	32GB
Memory Type	DDR4
Storage Interface	4 x SATA 6Gb/s
PCIe Slots	1 x PCIe 3.0/2.0 x16, 2 x PCIe 2.0 x1
USB Ports	6 x USB 2.0
Audio	Realtek ALC887 8-Channel High Definition Audio
LAN	Realtek RTL8111H Gigabit LAN
Video Outputs	1 x VGA, 1 x HDMI
