Asus H110S2 User Manual

1-8
Chapter 1: Product introduction
System memory
Overview
ThismotherboardcomeswithtwoDoubleDataRate4(DDR4)SmallOutlineDualInline
MemoryModule(SO-DIMM)sockets.ThegureillustratesthelocationoftheDDR4SO-
DIMMsockets:
Channel
Sockets
ChannelA DIMM_A1
ChannelB DIMM_B1
• YoumayinstallvaryingmemorysizesinChannelAandChannelB.Thesystem
mapsthetotalsizeofthelower-sizedchannelforthedual-channelconguration.Any
excessmemoryfromthehigher-sizedchannelisthenmappedforsingle-channel
operation.
• AlwaysinstalltheDIMMSwiththesameCASLatency.Foranoptimumcompatibility,
werecommendthatyouinstallmemorymodulesofthesameversionordatacode
(D/C)fromthesamevendor.Checkwiththevendortogetthecorrectmemory
modules.
• Whenyouinstallonlyonememorymodule,installittoDIMM_A1slotforthe
motherboardtoworkproperly.
• Thismotherboardsupports1.2VDDR4DIMMs.
• Duetothememoryaddresslimitationon32-bitWindows
®
OS,whenyouinstall4GB
ormorememoryonthemotherboard,theactualusablememoryfortheOScanbe
about3GBorless.Foreffectiveuseofmemory,werecommendthatyoudoanyofthe
following:
- Useamaximumof3GBsystemmemoryifyouareusinga32-bitWindows
®
OS.
 - Installa64-bitWindows
®
OSifyouwanttoinstall4GBormoreonthe
motherboard.
 - Formoredetails,refertotheMicrosoft
®
supportsiteathttp://support.microsoft.
com/kb/929605/en-us.
VisittheASUSwebsiteatwww.asus.comforthelatestQVL.
DIMM_A1
DIMM_B1
Installing a DIMM
1 2
To remove a DIMM
B
A
B
B
A
A
A

Asus H110S2 Specifications

General

Form Factor	Mini-ITX
Socket Type	LGA 1151
Chipset	Intel H110
Memory Slots	2 x DIMM
Maximum Memory	32GB
Memory Type	DDR4
Expansion Slots	1 x PCIe 3.0 x16
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
Storage Interface	4 x SATA III
USB Ports	4 x USB 3.0
Video Outputs	HDMI
LAN	1 x Gigabit LAN
