Asus H81M-C User Manual

vi
H81M-C specications summary
(continued on the next page)
CPU LGA1150 socket for 4th Generation Intel
®
Core
TM
i7/i5/i3, Pentium
®
,
Celeron
®
Processors
Supports Intel
®
22nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
H81 Express Chipset
Memory 2 x DIMM, max. 16GB, DDR3 1600 / 1333 / 1066 MHz, non-ECC, un-
buffered memory*
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual CPUs.
Please refer to the Memory QVL (Qualied Vendors List) for details.
** Refer to www.asus.com for the latest Memory QVL (Qualied Vendors List).
*** Due to Intel
®
chipset limitation, the DDR3 1600MHz and higher memory
modules on XMP mode will run at the maximum transfer rate of DDR3 1600MHz.
Graphics Multi-VGA output support: D-SUB, DVI-D ports
- Supports DVI-D with max.resolution of 1920 x 1200 @60Hz
- Supports D-SUB with max. resolution of 1920 x 1200 @60Hz
Maximum shared memory of 1024 MB
Expansion slots 1 x PCI Express 2.0 x16 slot
2 x PCI Express 2.0 x1 slots
1 x PCI slot
Storage Intel
®
H81 Express Chipset:
- 2 x Serial ATA 6.0 Gb/s connector (yellow)
- 2 x Serial ATA 3.0 Gb/s connector (dark brown)
Audio Realtek
®
ALC887 7.1-channel Audio CODEC
- Supports jack-detection, multi-streaming, front panel jack-restasking
* Use a chassis with HD audio module in the front panel to support an 7.1-channel
audio output.
LAN
Realtek 8111G PCIe Gigabit LAN controller
Package contents
Check your motherboard package for the following items.
Motherboard ASUS H81M-C motherboard
Cables 2 x Serial ATA 6.0 Gb/s cables
Accessories 1 x I/O Shield
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.

Asus H81M-C Specifications

General

Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1666 MHz
Processor socket	LGA 1150 (Socket H3)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
S/PDIF out connector	Yes
Number of COM connectors	1
Number of SATA connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H81
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Supported storage drive interfaces	SATA II, SATA III
Maximum resolution	1920 x 1200 pixels
Maximum graphics card memory	1024 MB
Parallel processing technology support	Not supported
Cables included	SATA
LAN controller	Realtek RTL8111G
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	2.0a
BIOS memory size	64 Mbit
