66 Notebook PC User Manual
The built-in network cannot be installed later as an upgrade.
After purchase, network can be installed as an expansion card.
Connections
Network Connection
Connect a network cable, with RJ-45 connectors on each end, to the
modem/network port on the Notebook PC and the other end to a
hub or switch. For 100 BASE-TX / 1000 BASE-T speeds, your network
cable must be category 5 or better (not category 3) with twisted-pair
wiring. If you plan on running the interface at 100/1000Mbps, it must
be connected to a 100 BASE-TX / 1000 BASE-T hub (not a BASE-T4
hub). For 10Base-T, use category 3, 4, or 5 twisted-pair wiring. 10/100
Mbps Full-Duplex is supported on this Notebook PC but requires
connection to a network switching hub with “duplex” enabled. The
software default is to use the fastest setting so no user-intervention
is required.
1000BASE-T (or Gigabit) is only supported on selected models.

Asus K55VJ Specifications

General

Graphics	NVIDIA GeForce GT 635M
Memory Expansion	Up to 8GB
Card Reader	2 -in-1 card reader ( SD/ MMC)
Audio	Built-in Speakers And Microphone, SonicMaster
Processor	Intel Core i7-3630QM
RAM	4GB DDR3
Storage	500GB / 750GB / 1TB HDD
Display	15.6-inch, 1366 x 768 pixels
Operating System	Windows 8
Battery	6-cell, 4700 mAh
Weight	2.6 kg
Chipset	Intel HM76 Express
Optical Drive	Super-Multi DVD
Camera	VGA webcam
Networking	802.11 b/g/n
Interface	USB 2.0, USB 3.0, HDMI, VGA, RJ-45, Headphone-out, Microphone-in
Power Adapter	Output: 19 V DC, 4.74 A, 90 W
