Chapter 1: Knowing the Parts
1-6
3
Battery Lock
The battery lock secures the battery pack. When the battery pack
is properly installed, it automatically locks in place. To remove the
battery pack, slide the battery lock inward.
Memory Compartment
The memory module is secured in a dedicated compartment.
2
Front Side
Refer to the diagram below to identify the components on this side of the
Eee PC.
1
Audio Speaker System
Audio features are software controlled.
