2-14 Chapter 2: BIOS information
2.4.4 Onboard Device Conguration
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address. Conguration options: [Disabled]
[3F8/IRQ4][2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
Parallel Port Address [378]
Allows you to select the Parallel Port base addresses. Conguration options: [Disabled] [378]
[278] [3BC]
Parallel Port Mode [Normal]
Allows you to select the Parallel Port mode. Conguration options: [Normal] [EPP] [ECP]
[EPP+ECP]
Parallel Port IRQ [IRQ7]
Conguration options: [IRQ5] [IRQ7]
HDAudio Controller [Enabled]
Enables or disables the high denition audio controller. Conguration options: [Enabled]
[Disabled]
Front Panel Select [HD Audio]
Conguration options: [HD Audio] [AC97]
OnBoard LAN Controller [Enabled]
Conguration options: [Enabled] [Disabled]
OnBoard LAN Boot ROM [Disabled]
Conguration options: [Disabled] [Enabled]
Plug and Play O/S [No]
When this item is set to [No], BIOS congures all the devices in the system. When this item
is set to [Yes] and if you install a Plug and Play operating system, the operating system
congures the Plug and Play devices not required for boot. Conguration options: [No] [Yes]
2.4.5 PCIPnP
The PCI PnP menu items allow you to change the advanced settings for PCI/PnP devices.
The menu includes setting IRQ and DMA channel resources for either PCI/PnP or legacy ISA
devices, and setting the memory size block for legacy ISA devices.
Take caution when changing the settings of the PCI PnP menu items. Incorrect eld values
can cause the system to malfunction.
Frame Buffer Location [Above 4G]
Conguration options: [Below 4G] [Above 4G]
AMD 760 HDMI Audio [Enabled]
Enables or disables the AMD 760 HDMI Audio. Conguration options: [Disabled] [Enabled]
