1.1 Special features
1.1.1 Product highlights
AMD
®
FX™ / Phenom™ II / Athlon™ II / Sempron™ 100 series CPU support
This motherboard supports AMD
®
Socket AM3+ multi-core processors with unique L3
cache and delivers better overclocking capabilities with less power consumption. It features
dual-channel DDR3 memory support and accelerates data transfer rate up to 5200MT/s via
HyperTransport™ 3.0-based system bus. This motherboard also supports AMD
®
CPUs in the
new 32nm manufacturing process.
HyperTransport™ 3.0 support
HyperTransport™ 3.0 technology provides 2.6 times more bandwidth than HT1.0 that
radically improves system efciency for a smoother and faster computing environment.
AMD
®
Cool ‘n’ Quiet Technology
This motherboard supports the AMD
®
Cool ‘n’ Quiet technology which monitors system
operation and automatically adjusts CPU voltage and frequency for a cool and quiet
operating environment.
Dual-Channel DDR3 1866 support
This motherboard supports DDR3 memory that features data transfer rates of 1866 /1600
/1333/1066 MHz to meet the higher bandwidth requirements of the latest operating system,
3D graphics, multimedia, and Internet applications.
Hybrid CrossFireX™ support
ATI Hybrid CrossFireX™ technology greatly boosts graphics performance with an onboard
GPU and a discrete GPU.
* Hybrid CrossFireX™ is supported by Windows
®
Vista or later versions only.
** Refer to www.amd.com for the discrete GPUs that support Hybrid CrossFireX™.
Gigabit LAN solution
The onboard LAN controller is a highly integrated Gb LAN controller. It is enhanced with an
ACPI management function to provide efcient power management for advanced operating
systems.
Serial ATA 3Gb/s technology and RAID support
This motherboard supports hard drives based on the Serial ATA (SATA) 3Gb/s storage
specication, delivering enhanced scalability and doubling the bus bandwidth for high-speed
data retrieval and save. It also supports RAID 0, RAID 1, and RAID 0+1 congurations for
Serial ATA hard drives.
Product introduction
1
ASUS M5A78L-M LX3 Series
1-1

Asus M5A78L-M LX3 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 1866 MHz
Processor socket	Socket AM3+
Processor manufacturer	AMD
Compatible processor series	AMD Phenom
Processor thermal power (max)	95 W
Number of SATA II connectors	4
Number of EATX power connectors	1
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
S/PDIF in port	No
Controller interface type	AMD SB710
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Component for	PC
Power source type	ATX
Motherboard chipset	AMD 760G
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 10, JBOD
Supported storage drive interfaces	SATA, SATA II
Graphics card	Radeon HD 3000
DirectX version	10
Maximum resolution	2560 x 1440 pixels
Graphics card family	ATI
Maximum graphics card memory	1024 MB
Parallel processing technology support	Hybrid CrossFireX
PCI Express slots version	2.0
Cables included	SATA
Networking features	Gigabit Ethernet
BIOS type	AMI
ACPI version	2.0a
BIOS memory size	16 Mbit

Weight and Dimensions

Depth	188 mm
Width	244 mm
