2-10 Chapter 2: BIOS information
2.4.1 JumperFree Conguration
2.4 Advanced menu
The Advanced menu items allow you to change the settings for the CPU and other system
devices.
Take caution when changing the settings of the Advanced menu items. Incorrect eld
values can cause the system to malfunction.
v02.61 (C)Copyright 1985-2011, American Megatrends, Inc.
M5A78L Series BIOS Setup
Main Advanced Power Boot Tools Exit
JumperFree Conguration
CPU Conguration
Chipset
Onboard Devices Conguration
PCIPnP
USB Conguration
Select Screen
Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
Adjust System
Frequency/Voltage etc.
Advanced Settings
The items and conguration options in this menu may vary depending on the AMD CPU
type.
CPU Overclocking [Auto]
Selects the CPU overclocking options to achieve desired CPU internal frequency.
Conguration options: [Manual] [Auto] [Overclock Prole] [Test Mode]
Version 0202
The following item only appears when you set CPU Overclocking to [Manual].
CPU/HT Reference Clock (MHz) [200]
Sets the CPU/HT Reference Clock. Conguration options: [Min.=200] [Max.=550]
The following item only appears when you set CPU Overclocking to [Overclock Prole].
Overclock Options [Auto]
Selects the overclocking prole. Conguration options: [Auto] [Overclock 2%] [Overclock 5%]
[Overclock 8%] [Overclock 10%]

Asus M5A78L Specifications

General

Memory channels	Dual-channel
Number of memory slots	4
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000 MHz
Processor socket	Socket AM3
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II X2, AMD Phenom II X4, AMD Phenom II X6
USB 2.0 connectors	3
S/PDIF out connector	Yes
Number of SATA II connectors	6
PS/2 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC887
Component for	PC
Motherboard chipset	AMD 760G
Audio output channels	7.1 channels
Motherboard form factor	ATX
Motherboard southbridge	AMD SB710
Compatible operating systems	-
On-board graphics card	No
Parallel processing technology support	Not supported
RAID levels	0, 1, 10, JBOD
Trial software	Antivirus
Bundled software	ASUS PC Probe II ASUS Update
LAN controller	Realtek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	2.0a
BIOS memory size	16 Mbit
