xii
Back Panel I/O Ports
Internal I/O
Connectors
BIOS features
Industry standard
Manageability
Form Factor
Support CD contents
Accessories
A7V8X specifications summary
* Specifications are subject to change without notice.
1 x Parallel
2 x Serial
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x Audio I/O (on audio model only)
4 x USB 2.0
1 x RJ-45 Port (on LAN model only)
CPU/Power/Chassis FAN connectors
20 pin ATX power connector
IDE LED connector
Chassis Intrusion, SM Bus, SIR
Smart Card reader connector
Front panel audio connector (on audio model only)
Game port
S/PDIF in/out connector (on audio model only)
CD/AUX/Modem audio in (on audio model only)
2 x 1394 port (on 1394 model only)
1 x USB 2.0 connector supports additional 2 USB 2.0 ports
2 x Serial ATA port (on serial ATA model only)
4Mb Flash ROM, Award BIOS, TCAV, PnP, DMI2.0, WfM2.0,
SM BIOS2.3, Multi-language BIOS, ASUS EZ Flash, ASUS
MyLogo2
PCI 2.2, USB 2.0
WfM 2.0. DMI 2.0, chassis intrusion, SMBus
ATX form factor: 12 in x 9.6 in (30.5 cm x 24.5 cm)
Device drivers
ASUS PC Probe
Trend Micro
tm
PC-cillin 2002 anti-virus software
ASUS LiveUpdate Utility
InterVideo WinCinema [WinDVD/WinRip/WinCorder/
WinProducer] software (optional)
User’s manual
Support CD
2 x UltraDMA 133/100/66 cable
IDE cable
FDD cable
I/O shield
2-port USB 2.0/ Game port module
2-port IEEE 1394 module (on 1394 model only)
2 x IEEE 1394 cable (on 1394 model only)
2 x Serial ATA cable (on Serial ATA model only)
