Asus P5KPL User Manual

ASUS P5KPL 2-15
2.3 Main menu
When you enter the BIOS Setup program, the Main menu screen appears, giving
you an overview of the basic system information.
2.3.1 System Time [xx:xx:xx]
Allows you to set the system time.
2.3.2 System Date [Day xx/xx/xxxx]
Allows you to set the system date.
2.3.3 Legacy Diskette A [1.44M, 3.5 in.]
Sets the type of oppy drive installed. Conguration options: [Disabled] [360K,
5.25 in.] [1.2M, 5.25 in.] [720K, 3.5 in.] [1.44M, 3.5 in.] [2.88M, 3.5 in.]
Refer to section “2.2.1 BIOS menu screen” for information on the menu screen
items and how to navigate through them.
Use [ENTER], [TAB]
or [SHIFT-TAB] to
select a eld.
Use [+] or [-] to
congure system time.
System Time [01:31:13]
System Date [Wed 01/09/2002]
Legacy Diskette A [1.44M, 3.5 in]
Primary IDE Master :[Not Detected]
Primary IDE Slave :[Not Detected]
SATA 1 :[Not Detected]
SATA 2 :[Not Detected]
SATA 3 :[ST380817AS]
SATA 4 :[Not Detected]
IDE Conguration
System Information
BIOS SETUP UTILITY
Main Advanced Power Boot Tools Exit
Select Screen
Select Item
Enter Go to Sub-screen
F1 General Help
F10 Save and Exit
ESC Exit

Asus P5KPL Specifications

General

Non-ECC	Yes
Number of memory slots	4
Maximum internal memory	4 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
USB 2.0 connectors	2
Number of EATX power connectors	1
Special features	ASUS CrashFreeBIOS3 ASUS EZ Flash2 ASUS Q-Fan ASUS MyLogo2
Manageability features	WOL @ PME, WOR @ PME, WOR @ Ring
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC662
Audio output channels	5.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows 2000/XP/Vista
Bundled software	ASUS PC Probe II ASUS LiveUpdate
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	193 mm
Width	350 mm
