Asus P5KPL User Manual

2-34 Chapter 2: BIOS setup
2.7 Tools menu
The Tools menu items allow you to launch special functions. Select an item then
press <Enter> to display the sub-menu.
Select Screen
Select Item
+-
Change Field
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
BIOS SETUP UTILITY
Main Advanced Power Boot Tools Exit
ASUS EZ Flash 2
Press ENTER to run
the utility to select
and update BIOS.
This utility doesn't
support :
1.NTFS format
ASUS EZ Flash 2
Allows you to run ASUS EZ Flash 2. When you press <Enter>, a conrmation
message appears. Use the left/right arrow key to select between [Yes] or [No],
then press <Enter> to conrm your choice. See page 2-3, section 2.1.2 for details.
ASUSTek EZ Flash 2 BIOS ROM Utility V3.06
Current ROM
Update ROM
A:
Note
[Enter] Select or Load [B] Backup [ESC] Exit
[Tab] Switch [Up/Down/Home/End] Move
FLASH TYPE: WOINBOND W25X80
PATH: A:\
BOARD: P5KPL
VER: 0123
DATE: 07/17/07
BOARD: Unknown
VER: Unknown
DATE: Unknown
This function only supports FAT 32/16 format.
Select Screen
Select Item
Enter Go to Sub-screen
F1 General Help
F10 Save and Exit
ESC Exit

Asus P5KPL Specifications

General

Non-ECC	Yes
Number of memory slots	4
Maximum internal memory	4 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
USB 2.0 connectors	2
Number of EATX power connectors	1
Special features	ASUS CrashFreeBIOS3 ASUS EZ Flash2 ASUS Q-Fan ASUS MyLogo2
Manageability features	WOL @ PME, WOR @ PME, WOR @ Ring
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC662
Audio output channels	5.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows 2000/XP/Vista
Bundled software	ASUS PC Probe II ASUS LiveUpdate
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	193 mm
Width	350 mm
