xi
P5W DH Deluxe specications summary
CPU LGA775 socket for Intel
®
Pentium
®
4/Celeron
®
processor
Supports Intel
®
Pentium
®
Processor Extreme Edition and
Intel
®
Pentium
®
D Processor
Supports Intel
®
next generation 65 nm and IntelIntel
®
Core
™
2
Duo/IntelIntel
®
Core
™
2 Extreme processorsprocessors
Supports Intel
®
next generation Multi-Core processor
Compatible with Intel
®
05B/ 05A and 04B/04A processors
Intel
®
EM64T and Hyper-Threading Technology ready
Chipset Intel® 975X
Intel® ICH7R
Front Side Bus 1066 / 800 MHz
Memory Dual-channel memory architecture
- 4 x 240-pin DIMM sockets support ECC/non-ECC
DDR2 800/667/533 MHz memory modules
- Supports up to 8 GB system memory
Intel
®
MPT (Intel
®
Memory Pipeline Technology)
ASUS Hyper Path3
Note: Visit the ASUS website at www.asus.com for the latest Qualied
Vendors List (QVL).
Expansion slots 2 x PCI Express™ x16 slots for discrete graphics card
2 x PCI Express™ x1 slots
3 x PCI slots
CrossFire™ Supports ATI CrossFire™ graphics cards (both at x8
mode)
ASUS Two-slot thermal design
ASUS PEG Link
Advanced Thermal
Design
ASUS 8-Phase Power Design
ASUS Stack Cool 2
ASUS Fanless Design: Heat-pipe thermal solution
Storage/RAID Intel
®
ICH7R Southbridge supports:
- 1 x Ultra DMA 100/66/33
- 3 x Serial ATA 3.0 Gb/s devices with RAID 0,1, 5
conguration
- Intel
®
Matrix Storage Technology
Jmicron
®
JMB363 Serial ATA controller supports:
- 1 x External Serial ATA 3.0 Gb/s (SATA-on-the-Go)
- 1 x Internal Serial ATA 3.0 Gb/s with RAID 0, 1
conguration with External Serial ATA 3.0 �b/sExternal Serial ATA 3.0 Gb/s
- 1 x Ultra DMA 100/66/33 connector for two devices
Note: Do not remove/unplug the External SATA device when running under
RAID mode.
Silicon Image
®
4723 Hardware RAID controller
(ASUS EZ-Backup) supports:
- 2 x Serial ATA 3.0 Gb/s with RAID 0 and RAID 1
conguration
(continued on the next page)
