Asus P5W DH User Manual

ASUS P5W DH Deluxe 5-27
OS conguration
To congure ASUS Music Alarm in Windows
®
1. Place the support CD into the optical drive.
2. Click the Utilities tab and choose ASUS Music Alarm to install the utility.
3. Insert an audio CD into the optical drive.
4. Launch the ASUS Music Alarm application by going to Start > ASUS > ASUS
Music Alarm. The main window appears.
Alarm information section
shows the alarm time and
days
Music section
shows the drive letter of the
chosen optical drive and the
starting track number to use
as music alarm
Minimize button
Exit button
Options section
shows playing options
5. Click the arrow ( ) next to Time
for Next Alarm in the Alarm
information section. The Alarm
Time Setting panel appears. Set
the days and time of the alarm, or
enable/disable the Music Alarm
feature.
When done, click OK.
6. Click the arrow ( ) next to Music in the Music
section. The Music Selection panel appears.
Select the optical storage device, then choose
the starting CD track number from which you
would like the music alarm to play.
When done, click OK.

Asus P5W DH Specifications

General

Chipset	Intel 975X
Socket	LGA 775
FSB	1066/800/533 MHz
Memory Type	DDR2
Maximum Memory	8GB
Memory Standard	DDR2 800/667/533
Form Factor	ATX
Audio Chipset	ADI AD1988B
LAN Speed	10/100/1000 Mbps
Storage	4 x SATA 3Gb/s
SATA RAID	RAID 0, 1, 5, 10
PS/2	2
USB 2.0	8 x USB 2.0
IEEE 1394	2 x IEEE 1394a
Audio Ports	6 Ports
Supported CPU	Core 2 Extreme / Core 2 Duo / Pentium D / Pentium 4 / Celeron
Memory Slots	4
Audio	8-channel
LAN	Dual LAN
LAN Chipset	Marvell 88E8053
Expansion Slots	2 x PCIe x16
S/PDIF Out	Optical
