ASUS P5W DH Deluxe 5-33
6. Use the up/down arrow key to select the stripe size for the RAID 0 array, then
press <Enter>. The available stripe size values range from 4 KB to 128 KB.
The default stripe size is 128 KB.
WARNING: ALL DATA ON SELECTED DISKS WILL BE LOST.
Are you sure you want to create this volume? (Y/N):
9. Press <Y> to create the RAID volume and return to the main menu, or <N> to
go back to the Create Volume menu.
7. Key in the RAID volume capacity that you want, then press <Enter>. The
default value indicates the maximum allowed capacity.
8. Press <Enter> when the Create Volume item is highlighted. This warning
message appears.
TIP: We recommend a lower stripe size for server systems, and a higher stripe
size for multimedia computer systems used mainly for audio and video editing.

Asus P5W DH Specifications

General

Chipset	Intel 975X
Socket	LGA 775
FSB	1066/800/533 MHz
Memory Type	DDR2
Maximum Memory	8GB
Memory Standard	DDR2 800/667/533
Form Factor	ATX
Audio Chipset	ADI AD1988B
LAN Speed	10/100/1000 Mbps
Storage	4 x SATA 3Gb/s
SATA RAID	RAID 0, 1, 5, 10
PS/2	2
USB 2.0	8 x USB 2.0
IEEE 1394	2 x IEEE 1394a
Audio Ports	6 Ports
Supported CPU	Core 2 Extreme / Core 2 Duo / Pentium D / Pentium 4 / Celeron
Memory Slots	4
Audio	8-channel
LAN	Dual LAN
LAN Chipset	Marvell 88E8053
Expansion Slots	2 x PCIe x16
S/PDIF Out	Optical
