Asus P5W DH User Manual

ASUS P5W DH Deluxe 1-5
Multi-RAID solution
Onboard RAID controllers provide the motherboard with multiple RAID functionality
that allows you to select the best RAID solution using Serial ATA devices.
• ASUS EZ-Backup. Enabled by Silicon Image’s SiI4723 controller, ASUS
EZ-Backup provides ready-to-go hardware RAID for plug-and play RAID 1 and
easy-to-congure RAID 0 sets of two hard disk drives
• Intel
®
ICH7R Southbridge RAID provides RAID level 5 support for three or
more hard disk drives.
• Cross-RAID allows you to build a RAID 10 set through a cross-conguration of
ASUS EZ-Backup and Intel
®
ICH7R.
• JMicron
®
RAID. Enabled by JMicron
®
JMB363 controller, JMicron
®
RAID
extends the advantages of software RAID beyond internal hard disk drives to
an external disk or external, port-multiplier enabled enclosure.
Refer to Chapter 5 for details on how to congure RAID.
Dual Gigabit LAN solution
The motherboard comes with dual Gigabit LAN controllers to provide the total
solution for your networking needs. These network controllers use the PCI Express
segment to provide faster data bandwidth for your wired or wireless Internet, LAN,
and le sharing requirements. See page 2-28 for details.

Asus P5W DH Specifications

General

Chipset	Intel 975X
Socket	LGA 775
FSB	1066/800/533 MHz
Memory Type	DDR2
Maximum Memory	8GB
Memory Standard	DDR2 800/667/533
Form Factor	ATX
Audio Chipset	ADI AD1988B
LAN Speed	10/100/1000 Mbps
Storage	4 x SATA 3Gb/s
SATA RAID	RAID 0, 1, 5, 10
PS/2	2
USB 2.0	8 x USB 2.0
IEEE 1394	2 x IEEE 1394a
Audio Ports	6 Ports
Supported CPU	Core 2 Extreme / Core 2 Duo / Pentium D / Pentium 4 / Celeron
Memory Slots	4
Audio	8-channel
LAN	Dual LAN
LAN Chipset	Marvell 88E8053
Expansion Slots	2 x PCIe x16
S/PDIF Out	Optical
